Description
With a compact design and integrated 24V PoE passthrough, airCube AC is a high-performance home Wi-Fi access point made to interoperate with airMAX CPE devices, with remote management by UISP.
Features:
- 802.11ac 2x2
- 24V PoE in and out or power in via included PSU
- UISP Mobile app support for fast setup
- UISP support for remote network management
Product Specifications
| ACB-AC | |
|---|---|
| Dimensions | 87.80 x 89.50 x 89.25mm (3.46 x 3.52 x 3.51") |
| Weight | 280 g (9.88 oz) |
| Management Interface | Wi-Fi / Ethernet |
| Networking Interface | (4) Gigabit Ethernet Ports |
| LED | Status |
| Operating Frequency | 2.4 GHz 5 GHz |
| Antenna Gain 2.4 GHz 5 GHz | 4 dBi 5 dBi |
| Max. Speeds 2.4 GHz 5 GHz | 300 Mbps 866.7 Mbps |
| Max. Power Consumption | 8.5W |
| Max. TX Power | 22 dBm |
| Power Supply | 24VDC |
| Power Method | 24VDC, 0.83A PoE 24V In on Ethernet Port 1 |
| PoE Out | Controllable 24V PoE Out (4, 5+, 7, 8-) on WAN Port |
| Supported Voltage Range | 22-26V |
| Operating Temperature | -10 to 50° C (-14 to 122° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| ESD/EMP Protection | ± 24 kV Contact / Air |
| Certifications | CE, FCC, IC |
