Ubiquiti airFiber X Antenna 2.4GHz, 24dBi Slant 45

UbiquitiSKU: AF-2G24-S45
Price:
$364.25

Tax included

Stock:
Sold out

Description

The airFiber® X Antennas feature significant advances in noise isolation and beam performance to complement the airFiber X radios for carrier backhauls and Point-to-Point (PtP) bridging.

Product Specifications

AF-2G24-S45
Dimensions650 x 650 x 295 mm
(25.6 x 25.6 x 11.6")
Weight9.8 kg
(21.61 lb)
Frequency2.3 - 2.7 GHz
Gain24 dBi
+45° Beamwidth6.6° (3 dB)
-45° Beamwidth6.8° (3 dB)
Front-to-Back Ratio28 dB
Max. VSWR1.6:1
Wind Survivability200 km/h
(125 mph)
Wind Loading787 N @ 200 km/h
(177 lbf @ 125 mph)
PolarizationDual Linear
Cross-Pol Isolation35 dB Min.
ETSI SpecificationEN 302 326 DN2
MountingUniversal Pole Mount, airFiber X Radio Bracket, and Weatherproof RF Jumpers Included
