Description
airMAX AC 60 GHz/5 GHz Radio with 1+ Gbps Throughput and Up to 2 km Range
Featuring a high-gain dish antenna, the GigaBeam LR is an airMAX 60 GHz radio designed for low-interference and high-throughput connectivity of up to 1+ Gbps in long-range deployments of up to 2 km. The GigaBeam LR includes a 5 GHz radio for 60GHz link failover. Easy setup can be done via UISP app.
Features:
- 60 GHz radio with 5 GHz radio backup
- Low-interference 60 GHz spectrum
- Up to 1+ Gbps with low latency
- Long-range performance
- 2.4 GHz management radio
- Full bandwidth support: 2.16 GHz
Product Specifications
| GBE-LR | |
|---|---|
| Dimensions | 415 x 415 x 303 mm (16.34 x 16.34 x 11.93") |
| Weight Without Mount With Mount | 1.4 kg (3.09 lb) 1.8 kg (3.97 lb) |
| Enclosure | Aluminum, UV-stabilized Polycarbonate |
| Antenna Gain 5 Ghz 60 Ghz | 11 dBi 38 dBi |
| Networking Interface | (1) 10/100/1000 Mbps Ethernet Port |
| Max. Power Consumption | 11W |
| Power Method | Passive PoE, Pins 4, 5+ and 7, 8- |
| Power Supply | 24VDC, 0.5A Gigabit PoE Adapter (Included) |
| Voltage Range | +22 to +26VDC |
| LEDs | Power/Ethernet/5G/60G |
| Wind Loading | 56 N @ 200 km/h |
| Wind Survivability | 200 km/h (125 mph) |
| Mounting | Pole Mount (Included) |
| ESD/EMP Protection | ± 24kV Contact/Air |
| Operating Temperature | -40 to 60° C (-40 to 140° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | FCC, IC, CE |
| Radio | |
| Max. Conducted TX Power 5/60 GHz Combined | 25 dBm |
| Channel Bandwidth 60 Ghz 5 Ghz | 2160 Mhz 20/40/80 Mhz |
| Operating Frequency (Mhz) | |
| US/CA U-NII-1 U-NII-2A U-NII-2C U-NII-3 | 5150 - 5250 5250 - 5350 5470 - 5725 5725 - 5850 57,000 – 66,000 |
| Worldwide | 5180 – 5875 57,000 - 66,000 |
| Management Radio (Mhz) | |
| Worldwide | 2412 - 2472 |
| US/CA | 2412 - 2462 |
