Description
Compact, UISP-ready WiFi radio sporting a classic NanoStation design and an updated airMAX AC chipset.
Classic NanoStation design with updated proprietary airMAX ac chipset and dedicated management Wi-Fi for easy UISP mobile app support and fast setup. Excellent solution for a simple PtP bridge or use as a PtMP station (CPE).
Features:
- New antenna
- Improved design
- Management Wi-Fi Radio/UISP mobile app
- AirOS 8
Product Specifications
| NanoStation | |
|---|---|
| Dimensions | 179 x 77.5 x 59.1 mm (7.05 x 3.05 x 2.33") |
| Weight | 0.18 kg (6.35 oz) |
| Processor | MIPS 74K |
| Memory | 128 MB |
| Gain | 13 dBi |
| Channel Bandwidth | 10/20/30/40/50/60/80 MHz |
| Networking Interface | 10/100/1000 Mbps Ethernet Port |
| LEDs | Power, Ethernet, (4) Signal Strength |
| Power Method | Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Power Supply | 24V, 0.5A Gigabit PoE Supply (Not Included) |
| Max. Power Consumption | 8.5W |
| Supported Voltage Range | 24V ±10% |
| Operating Temperature | -40 to 70° C (-40 to 158° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
