Description
High-performance router with a built-in Layer 2 switch, (10) Gigabit RJ45 ports, and (2) SFP ports.
The EdgeRouter 12 is a high-performance Gigabit Router with PoE flexibility. With increased performance over the previous generation of routers, the EdgeRouter 12 delivers up to 3.4 million pps for 64-byte packets. Ten Gigabit Ethernet ports offer copper connectivity, while two SFP ports offer fiber connectivity. The EdgeRouter 12 supports Layer-2 switching and scalable configuration using EdgeOS or UISP.
Compatible with EdgeMAX Universal Rack-mount Kit - Sold separately
Product Specifications
| EdgeRouter 12 | |
|---|---|
| Dimensions | 268.1 x 136.5 x 31.1 mm (10.55 x 5.37 x 1.22") |
| Weight | 700 g (1.54 lb) |
| Max. Power Consumption | 20W (Excludes PoE Output) |
| Power Method | External AC/DC Power Adapter, 24W (24V, 1A) (Included) 24V Passive PoE |
| Power Supply | External AC/DC Adapter |
| Passive PoE Voltage Range Max. Wattage per Port | DC/PoE Passthrough 20W (24V) |
| Supported Voltage Range | 9 - 30VDC |
| Button | Reset |
| LEDs System Data Ports SFP Data Port | Power Speed/Link/Activity;PoE (Ports 0 and 9 only) Link/Activity |
| Processor | 4-Core 1 GHz MIPS64 |
| System Memory | 1 GB DDR3 RAM |
| On-Board Flash Storage | 4 GB eMMC, 8 MB SPI NOR |
| ESD/EMP Protection | Air: ± 24 kV, Contact: ± 24 kV |
| Interfaces Management Networking | (1) RJ45 Serial Port, (10) Ethernet Ports (Default Port 0) (10) 10/100/1000 RJ45 Ports Port 0 Supports PoE IN; Port 9 Supports PoE Out (2) 1 Gbps SFP Ports |
| Operating Temperature | -10 to 50° C (14 to 122° F) |
| Operating Humidity | 10 - 90% Noncondensing |
| Certifications | CE, FCC, IC |
