Description
Fanless router with a four-core, 1 GHz MIPS64 processor, (3) Gigabit RJ45 ports, and an SFP port.
The all-new EdgeRouter 4 brings “high-performance at disruptive pricing” to a new level. With a 50% increase in performance compared to the EdgeRouter Pro, the EdgeRouter 4 delivers the performance your network needs. Paired with our feature-rich EdgeOS makes this a versatile tool in both Carrier-Grade and Enterprise networks.
Features:
- (3) Gigabit RJ45 Ports and (1) SFP Port
- 4-Core 1GHz MIPS64 Processor
- Internal PSU
- Fan-less
- Desk, wall, and rack-mount options*
Product Specifications
| EdgeRouter 4 | |
|---|---|
| Dimensions | 229 x 136.5 x 31.1 mm (9.02 x 5.37 x 1.22") |
| Weight | 795 g (1.75 lb) |
| Max. Power Consumption | 13W |
| Power Method | Universal AC Power Cord (C13) |
| Power Supply | Internal AC/DC Power Adapter, 30W DC |
| Supported Voltage Range | 100-240VAC, 50/60 Hz Universal Adapter |
| Button | Reset |
| LEDs Data Ports SFP Data Port | Speed/Link/Activity Link/Activity |
| Processor | 4-Core 1 GHz MIPS64 |
| System Memory | 1 GB DDR3 RAM |
| On-Board Flash Storage | 4 GB eMMC, 8 MB SPI NOR |
| ESD/EMP Protection | Air: ± 24 kV, Contact: ± 24 kV |
| Management Interfaces | (1) RJ45 Serial Port (4) Ethernet Ports (Default eth0) |
| Networking Interfaces | (3) 10/100/1000 RJ45 Ports (1) 1 Gbps SFP Port |
| Operating Temperature | -10 to 50° C (14 to 122° F) |
| Operating Humidity | 10 - 90% Noncondensing |
| Certifications | CE, FCC, IC |
