Ubiquiti EdgeSwitch 24 Lite

UbiquitiSKU: ES-24-Lite

Price:
Sale price$371.09

Tax included

Stock:
Sold out

Description

Layer 2/3 switch with (24) Gigabit RJ45 ports, (2) SFP ports, and a 25W power supply.

Advanced Switching Technology for the Masses. Build and expand your network with Ubiquiti EdgeSwitch™, part of the EdgeMAX® line of products. The EdgeSwitch is a fully managed, Gigabit switch, delivering robust performance and intelligent switching for growing networks. The EdgeSwitch offers an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability.

Features:

  • (24) Gigabit RJ45 Ports
  • (2) SFP Ports
  • (1) Serial Console Port
  • Non-Blocking Throughput: 26 Gbps
  • Switching Capacity: 52 Gbps
  • Forwarding Rate: 38.69 Mpps
  • Maximum Power Consumption: 25W
  • Rack- or Wall-Mountable
  • DC Input Option (Redundant or Stand-Alone)

Product Specifications

ES-48-LITE
Dimensions 443 x 43 x 221 mm
(17.44 x 1.69 x 8.70")
Weight
Rack-Mount Brackets Included
Rack-Mount Brackets Excluded

2.6 kg (5.7 lb)
2.51 kg (5.53 lb)
Total Non-Blocking Throughput 26 Gbps
Switching Capacity 52 Gbps
Forwarding Rate 38.69 Mpps
Max. AC Power Consumption 25W
Power Method
AC

100-240VAC/50-60 Hz, Universal Input
DC 25W, 25 to 16V, with 2.5 mm DC Power Inline Connector
Power Supply AC/DC, Internal, 25W DC
LEDs Per Port
Serial Console Port
RJ45 Data Ports
SFP+/SFP Data Ports

N/A
Speed/Link/Activity
Speed/Link/Activity
Networking Interfaces (24) 10/100/1000 Mbps RJ45 Ethernet Ports
(2) 1/10 Gbps SFP+ Ethernet Ports
Management Interface (1) RJ45 Serial Port, Ethernet In/Out Band
Certifications CE, FCC, IC
Rackmount Yes, 1U High
ESD/EMP Protection Air: ±24 kV, Contact: ±24 kV
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 5 to 95% Noncondensing
Shock and Vibration ETSI300-019-1.4 Standard
