Description
UISP-ready optical line terminal with (4) Gigabit optical network ports, (2) fiber uplinks, and Layer 2/3 switching capability.
Introducing UFiber OLT – a fiber solution that anyone can deploy. UFiber offers internet and telecom service providers a cost‑effective fiber optic delivery system for Triple Play Services (data, voice, IPTV/VoD) with speeds of up to 2.488 Gbps downstream and 1.244 Gbps upstream. The UFiber network is intelligently managed using the included UISP application. UFiber devices consist of the UFiber OLT or OLT-4 (deployed at the provider premises) and the UFiber Nano™ G,
loco, or UF-WiFi clients, which function as ONU CPEs (Customer Premises Equipment).
Features:
- 4-Port GPON Optical Line Terminal
- 4 Gigabit Passive Optical Network Ports
- Supports up to 512 Clients (128 per PON Port)
- Up to 2.488 Gbps TX and 1.244 Gbps RX
- One 1G/10G SFP+ Ethernet Ports
- Flexible Layer 2/3 Management Features
- Ethernet port for management
- Console serial port for management
- 24V DC Input Option (Redundant or Stand-Alone)
Product Specifications
| Dimensions | 299.8 X 258.95 X 42.55 mm |
| Weight | 1930g (without hangers) 2130g (with hangers) |
| Enclosure Characteristics | SGCC steel |
| HARDWARE | |
| Processor | MIPS 1004Kc 880 Mhz dual core |
| Memory | 512 Mbyte DDR3, 512M Byte NAND |
| Management Interface | (1) Ethernet out-of-band management (1) Ethernet in-band management (1) RJ45 Serial Console Port |
| Networking Interface | (4) GPON OLT SFP (1) 10 Gbps SFP+ |
| Buttons | (1) Reset, Press 5 seconds - Reset to default |
| LEDs/Display | (1) Power: Blue/White Blinking Blue: reset to default Steady Blue: system is booting Steady White: service is ready (4) GPON OLT SFP Steady/Blinking white : GPON link/activity (1) SFP+ Ethernet: White(10G) Green(1G), steady on after link is up, blinking while activity (1) Ethernet RJ45 Out-of-band Management: Green(1G), steady on after link is up, blinking while activity |
| Power Method | 100-240VAC/50-60 Hz universal input / 25VDC |
| Power Supply | AC/DC internal 56W DC / DC barrel jack connector |
| Supported Voltage Range | AC input: 100 to 240 VAC / 25 to 16VDC |
| Max. Power Consumption | 35W (Excluding SFP modules) |
| Operating Temperature | -10 to 45°C (14 to 113°F) |
| Operating Humidity | 10% to 90% Non-Condensing |
| SOFTWARE | |
| Mode | OLT 2/3 Ethertnet Switch and GPON Core |
| Advanced QoS | Support 8 priority queues per user port and traffic classification |
| Concurrent Clients | 512 ONUs/ONTs registered |
| Ubiquiti Specific Features | UBNT Discovery and UBNT mcagent |
| Minimum Software Requirements | Any Modern Web Browser |
